Mityvac Digital Diesel Compression Test Kit This comprehensive diesel engine compression test kit features an electronic tester that memorizes the peak compression value for each cylinder. When testing is complete, the values can be quickly reviewed at the push of a button. The kit also includes two (2) injector adapters and four (4) glow plug adapters for testing most modern diesel cars and light trucks sold in the United States.
Key source specifications include Model MV5535; Maximum Pressure: 1,000 psi/68.9 bar; Packaged Weight: 5.2 lbs.; Case Size: 15.7 x 12.4 x 3.2″.
Key Features
- Maximum Pressure: 1,000 psi/68.9 bar
- Packaged Weight: 5.2 lbs
- Case Size: 15.7 x 12.4 x 3.2″
- Mityvac Digital Diesel Compression Test Kit
- Stores maximum compression value for up to 12 cylinders
- Used Standard 9 V battery for convenience and cost
Not Ideal For
Not ideal for pressures above the listed 1,000 psi/68.9 bar maximum.
Product Details
Review the product details below to confirm the model / mpn, maximum pressure, packaged weight, case size match your equipment or lubrication system.
Shared Product Details
| Model / MPN | MV5535 |
| Brand | Mityvac |
| Maximum Pressure | 1,000 psi/68.9 bar |
| Packaged Weight | 5.2 lbs. |
| Case Size | 15.7 x 12.4 x 3.2″ |
Additional Product Information
Features:
- Backlit LC display is easy to read from any angle and in any light.
- Automatically shuts off after 3 minutes of non-use (memory is retained)
- Rubber boot protects the gauge from bumps and drops
- Sealed, grease- and oil-resistant gauge face prevents contamination of electronics
- Displays values in psi, bar and kPa
Includes:
- Digital compression tester comprising of test gauge with rubber boot, 15 in. long, high-pressure hose, quick-change coupler
- Adapters MVA5601, MVA5602, MVA5603, MVA5604, MVA5605,MVA5606, MVA5607
- Glow plug adapter (GM 4.3L, 5.7L (1978-1985), Navistar 6.9L, 7.3L through 1994)
- Glow plug adapter (GM 6.2L, 6.5LV8)
- Glow plug adapter (Ford/Navistar 7.3L power stroke (1994-2003))
- Glow plug adapter (Volkswagen 1.9L TDI)
- Right-angle adapter
- Field service kit
- Custom-molded case
Frequently Asked Questions
What model number should I verify?
Confirm model or manufacturer part number MV5535.
What pressure is listed?
The supplied specifications list 1,000 psi/68.9 bar.
